GEDA 2 PK

Compare

The GEDA 2 PK transports the crane operator to his workplace, quickly and, above all, safely. This means no more risky, arduous climbs in often poor weather conditions. The flexible system means the hoist can be installed on all crane types from all manufacturers, up to a height of 150 m as a standard.


Once the base unit of the rack and pinion hoist has been assembled and anchored, the aluminium ladder sections, weighing only 22 kg, are installed through the open cabin roof and easily mounted without screws, using the patented quick-release connections.


Comprehensive safety features complete the overall concept of the GEDA 2 PK. When opening the car, a small ramp with side protection folds down and, in conjunction with the access barrier on the crane, ensures safe access to the car. A speed-dependent safety gear guarantees safety, while electrical safety elements prevent operating errors.


The crane operator hoist can also act as a life saver in an emergency situation, as the recovery and rescue of unconscious or ill crane operators can be conducted very quickly with the GEDA 2 PK.


prev
next
Product highlights
Automatic lubrication device standard

The automatic lubrication system reduces maintenance costs.

Full crane load

Full crane load thanks to light design made of aluminium

Easy handling

Quick installation thanks to patented quick locking system

Ideal cable guide

Integrated, patented cable channel

Full crane load

Flexible supports guarantee the full crane load (Counteract bending and twisting)



Technical Data Refresh
Cargo Persons and material
Mast system alu-ladder (with rack)
Load capacity (material) 200 kg
Load capacity (persons) 2 Persons
Lifting height 150 m
Lifting speed 24 m/min
Power supply 1.5 kW / 400 V / 50 Hz / 16 A
Platform dimension 1.1 m x 0.6 m x 2.1 m
