Cable bin with trailing cable 25 m lifting height

Cable bin with trailing cable 50 m lifting height

Cable bin with trailing cable 75 m lifting height

Cable bin with trailing cable 100 m lifting height

Set of fixing brackets for individual transport frame (for scaffold assembly)

Ideal for use in the material mode (not in combination with roof)

Compatible with platform A, B and C.

Trailing cable guide

Electric cable 16 A, 400 V, 50 m length

Electric cable 16 A, 400 V, 25 m length

Uniaxial trailer 80 km/h (hot dip galvanised), automatic unloading without auxiliary devices

Set of extension tubes (2 m) for mast fi xing (to span a scaffold)

Assembly plank fo the load platform (small foldable platform to anchor the mast without existing scaffold)

Electric module "Up-Down-Emergency off"

Assembly plank for the load platform (small folding platform to anchor the hoist without existing scaffold)

Extension cord 20 m for electric module

Stop bar for landing level stop

Steel mast 1.5 m (hot dip galvanised) with four captive screws (M16) and nuts

Set of mast ties with fixing tubes

Support arm for easy opening of the landing level safety gate "Comfort", "Standard" and "Standard-Basic"

Cable bin cover with lock (theft protection)

Adapter for electric module (necessary when using the landing level safety gate “Standard” and “Standard-Basic” with sheet metal panel)

Retrofit kit for unloading ramp necessary for

using landing level safety gate "Premium" and

"Flexy"

Standard cartridge (380 g)

Grease for SIMPLE applications.

Yellow, semi-synthetic multi-Purpose grease without solid lubricants with a wide temperature range.

-30 °C up to +70 °C

Labels "Brake indicator" (set)

Refill gun for automatic lubrication system

Floor and wall tie for landing level safety gate

2 pcs. required for fastening onto a floor (and 2 tubes 1 ½” on site required)

4 pcs. required for fastening onto a wall (and 2 tubes 1 ½” on site required)

Jack ring for crane load capacity 1700 kg

Pre-fitting for „infobric“ access system

(„infobric“ access system not included)

Sliding door (1.5 m wide) for high base enclosure (temporary fences H=2 m and blocks on site required);

safety stop approx. 2 m above the ground is not required

Sliding door (1.1 m wide) for high base enclosure (temporary fences H=2 m and blocks on site required);

safety stop approx. 2 m above the ground is not required;

for platform "SL"

Initial lubrication set (2 cartridges and 1 brush)

Grease for SIMPLE applications.

Yellow, semi-synthetic multi-purpose grease without solid lubricants with a wide temperature range.

-30 °C up to +70 °C

Spare part boxes GEDA 500 Z/ZP basic set (suitable from serial number 21500-01352)

Set consisting of spare part boxes GEDA 500 Z/ZP:

- Electric-limit switches (Art. No. 67700)

- Electric-switch box (Art. No. 67701)

- Mechanical 1 (Art. No. 67703)

- Mechanical 2-small-parts (Art. No. 67704)

Spare part box GEDA 500 Z/ZP Extended set electric-switch box (V3)

(suitable from serial number 64500-03763)

Spare part box GEDA 500 Z/ZP Extended set electric-switch box (V2)

(suitable from serial number 55640-04446)

Landing level safety gate „Premium“ 1.1 m

height

Sheet metal panel for landing level safety gate "Comfort"

Sheet metal panel for landing level safety gate "Standard/Standard-Basic"

Use our IoT-Check-Tool to find out which retrofit kit you need for your device:

central.geda.de/iot_retrofit_tool

Not available in all countries! Further information at www.geda-smart.com

Electric module "Up-Down-Emergency" for

landing level safety gate "Flexy"

Landing level safety gate "Flexy" 1.1 m height

Not available in all countries! Further information at www.geda-smart.com
